REVOLUTIONARY RIC CABLE-AS-ANTENNA TECHNOLOGY
High-performance micro cable with integrated Bluetooth antenna
- Lowers power consumption
Removes unnecessary and power-consuming RF components - Saves PCB space
Frees up area by moving antenna out of the hearing aid device - Bendable with shape memory
Highly ductile micro cable for reliable daily use
With the es-Linum® Bluetooth Antenna, antenna and signal are combined in one micro cable, reducing system complexity, lowering energy use, and unlocking new design freedom for hearing aid development.
Built-in Bluetooth antenna
Revolutionary formable micro cable with built-in Bluetooth antenna. A true breakthrough combining antenna and conductors in one ultra-compact, patent-pending cable design.
Lower power consumption
Reduces overall power draw through fewer RF components. Enables longer battery life and simpler, more efficient circuit design.
Space-saving RIC design
Frees up PCB and housing space for compact RIC designs. Eliminates the need for separate antenna modules inside the shell.
Simplified architecture
Reduces component count and speeds
development. Streamlines design and tuning
in tight-fitting hearing aid layouts.
Shape-retaining cable
Highly bendable cable with firm shape retention. Resists mechanical fatigue and supports reliable daily use.
Reliable performance
Reliable performance from development to daily use. Built for consistent quality and cost efficiency throughout the product lifecycle.
High-tech cable with integrated antenna for RIC
The es-Linum® Antenna is a cutting-edge cable designed for seamless integration into Receiver-in-Canal (RIC) hearing aids.
Built on the same advanced shielding principles as the es-Linum® Shielded Cable, the es-Linum® Antenna combines micro-scale mechanical design with precise RF engineering.
The cable features a precisely tuned antenna section, matched to the Bluetooth wavelength and incorporating a carefully engineered gap in the shield that defines the antenna endpoint.
This design enables the cable to function both as a high-performance signal carrier (with 2–8 conductors) and as a directly integrated 2.4 GHz or 5.0 GHz Bluetooth antenna
The new antenna cable solution builds on the well-documented es-Linum® platform, founded on more than 30 years of expertise in micro connections.
Learn more about our es-Linum® cable programme and our capabilities.
Free up space with integrated antenna
By embedding the antenna within the cable itself, es-Linum® Antenna eliminates the need for additional space inside the hearing aid, making it an ideal solution for compact, high-tech designs without compromising performance. Applications: For use in Hearing Aids with Bluetooth connection, portable medical devices.
- Cable with Bluetooth antenna integrated
- Outer diameter of cable Ø1.1mm or Ø1.4mm
- Highly ductile cable
- Formable and with excellent shape memory
- Prevents acoustic feed-back
- Conductors twisted to reduce EMI
- REACH & RoHS compliant
- Cost-effective
The es-Linum® cables have an extensive track record, implemented in millions of RIC devices. Read more about our custom RIC Connector solutions.
es-Linum® Antenna delivers superior technology throughout the value chain
Technical performance
- Integrated Bluetooth antenna
- Stable signal performance
- Lowers power consumption
- Reduces component count
- Supports advanced features
Integration benefits
- Slim RIC form factor
- Saves PCB space
- Simplifies system architecture
- Easier Bluetooth integration
- Highly ductile cable
- Minimises acoustic feedback
Production & quality
- Consistent production quality
- Based on es-Linum® platform
- REACH & RoHS compliant
- Cost-effective integration
Market differentiation
- Revolutionary cable-as-antenna solution
- Power saving
- Unlocks new design freedom
- Differentiates product platforms
- Future-proof platform
- Built on decades of trust and co-development with leading hearing manufacturers.
Reach out for sample and information
Do you want to learn more about the brand new Cable-as-Antenna technology? Provide us your name and address and we will send you a sample and further information as soon as we can.
